Maximum length without splice

7300mm

Ladder post splice,solid square bar

38x38mm,200mm long

Maximum ladder length with cage

10200mm

Outside width(outside rail to rail)

500mm

Rung spacing(center to center)

300mm

Outside diameter of rung,fluted tube

32mm

Wall thickness of rung

6.4mm

Ladder post square tube

50.8x50.8x6.4mm

Ladder rung gasket

Black rubber

Rivet to fix rungs to ladder post

4x20mm

Top/Intermediate ladder hoop

76mm w x13mm t,hand lay up with predrilled holes

Bottom ladder hoop

76mm w x13mm t,hand lay up with predrilled holes

Hoop Bracket

75x140mm,10mm t,U shape.Predrilled holes

Cage Strip

C channel,50x14x3mm

Bottom wall mount bracket

76x200x9.5mm angle,457mm long

Wall bracket

76x200x9.5mm angle,152mm long,180mm from wall to center of rung

Floor mount

102x102x9.5mm angle

Foot base mount

Foot base
